Design Software Tools and Embedded Processing
Altera’s Customizable Processor Portfolio
www.altera.com/embedded
Altera’s processor portfolio comprises SoCs, which feature single- or dual-core ARM Cortex-A9 MPCore hard processor
systems as well as soft processors that can be used in any FPGA or SoC.
LOW-COST SoCs MIDRANGE SoCs
(Lowest Power, Form Factor, and Cost) (High Performance with Low Power, Form Factor, and Cost)
? 20 nm TSMC
HIGH-END SoCs
(Highest Performance and System Bandwidth)
? 14 nm Intel Tri-Gate
? 64 bit Quad
ARM A53 MPCore
? 28 nm TSMC
? 1.5 GHz Dual ARM
Cortex-A9 MPCore
? Optimized for Maximum
Performance per Watt
? 28 nm TSMC
? 925 MHz Dual ARM
Cortex TM -A9 MPCore TM
? 5 Gbps Transceivers
? 400 MHz DDR3
? 25 to 110K LEs
? Up to 224 Multipliers
(18x19)
? 1.05 GHz Dual ARM
Cortex-A9 MPCore
? 10 Gbps Transceivers
? 533 MHz DDR3
? Up to 462K LEs
? Up to 2,136 Multipliers
(18x19)
? 17 Gbps Transceivers
? 1333 MHz DDR4
? Up to 660K LEs
? Up to 3,300 Multipliers
(18x19)
? Over 4,000K LEs
LOGIC DENSITY
Summary of Processors
Category
Processor
Vendor
Description
Hard processors for SoC
Applications processing
Dual-core ARM
Cortex-A9
Altera
Altera’s 28 nm Cyclone V and Arria V SoC families and 20 nm Arria 10 SoCs offer integrated
ARM-based HPS, comprising peripherals, memory, and interfaces, with an FPGA fabric.
Soft processors
With unique, real-time hardware features, such as custom instructions (ability to use FPGA
Power- and cost-optimized
processing
Nios II economy
core
Altera
hardware to accelerate a function), vector interrupt controller, and tightly coupled memory,
as well as support for industry-leading real-time operating systems (RTOS), the Nios II processor
meets both your hard and soft real-time requirements.
With unique, real-time hardware features, such as custom instructions (ability to use FPGA
Real-time processing
Nios II standard
and fast core
Altera
hardware to accelerate a function), vector interrupt controller, and tightly coupled memory, as
well as support for industry-leading RTOS, the Nios II processor offers a versatile solution for
real-time processing.
A simple configuration option enables the Nios II fast core to use a memory management unit
Applications processing
Nios II fast core
Altera
to run embedded Linux. Both open source and commercially supported versions of
Linux for Nios II processors are available.
Safety-critical processing
Nios II SC
H-Cell
Certify your design for DO-254 compliance by using the Nios II Safety Critical core along with
the DO-254 compliance design services offered by H-Cell.
56
Altera Product Catalog
?
2013
?
www.altera.com
